XX-6CS - 0.31" Spring Steel Compression Spring

Inventory Status
Estimated Lead Time

Compression spring manufactured from spring steel with 3.5 coils and closed & ground ends. This spring features an O.D. of 0.296", and an I.D. of 0.176".

NOTE: The spring rate value for compression springs with 4 coils or less is a reference value.

Unit System
Specs (in standard)
Label Value
Brand Century Spring
Display Name XX-6
Ends Closed & Ground
Finish None
Free Length 0.31 in
Inside Diameter 0.176 in
Material Spring Steel
Outside Diameter 0.296 in
Part Type Standard
Rate 933 lbs/in
SKU XX-6CS
Solid Length 0.21 in
Suggested Max Deflection 0.03 in
Suggested Max Load 24 lbf
Total Coils 3.5
Wire Diameter 0.06 in
Specs (in metric)
Label Value
Brand Century Spring
Display Name XX-6
Ends Closed & Ground
Finish None
Free Length 7.87 mm
Inside Diameter 4.47 mm
Material Spring Steel
Outside Diameter 7.52 mm
Part Type Standard
Rate 163.37 N/mm
SKU XX-6CS
Solid Length 5.33 mm
Suggested Max Deflection 0.76 mm
Suggested Max Load 106.75 N
Total Coils 3.5
Wire Diameter 1.52 mm
The compression spring XX-6CS is an essential component designed for applications requiring reliable force and energy storage. Crafted from high-quality spring steel, the XX-6 compression spring design exhibits exceptional tensile strength and resilience.

The XX-6 design is manufactured with a free length of 0.31", with an outer diameter of 0.296", an inner diameter of 0.176", and a total of 3.5 coils, expertly designed to deliver consistent compression characteristics including a rate of 933 lbs/in.

The XX-6CS compression spring is ideally suited for use in a wide range of mechanical assemblies, including but not limited to automotive suspension systems, industrial machinery, and electronic devices.

In summary, the compression spring XX-6 design stands out for its superior material properties, thoughtful design, and versatility in application. It is a prime choice for engineers committed to excellence and innovation in their projects.
