D-1301CS - 1 Inch Chrome Alloy Die Spring

Inventory:
Estimated Lead Time

1 Inch Chrome Alloy die spring

Download CAD
Unit System
Specs (in standard)
Label Value
Average Life Deflection Force 19 lb
Brand Century Spring
Deflection For Average Life 0.15 in
Deflection For Long Life 0.2 in
Display Name D-1301
Duty Load Heavy
Finish None
Finish Color Gold
Free Length 1 in
Hole Size 0.375 in
Long Life Deflection Force 25 lb
Material Chrome Alloy
Maximum Deflection 0.3 in
Maximum Deflection Force 37 lb
Measurement Units Standard
Rate 124 lbs/in
Rod Size 0.1875 in
SKU D-1301CS
Wire Diameter 0.072 in x 0.054 in
Specs (in metric)
Label Value
Average Life Deflection Force 8.62 kg
Brand Century Spring
Deflection For Average Life 3.81 mm
Deflection For Long Life 5.08 mm
Display Name D-1301
Duty Load Heavy
Finish None
Finish Color Gold
Free Length 25.4 mm
Hole Size 9.53 mm
Long Life Deflection Force 11.34 kg
Material Chrome Alloy
Maximum Deflection 7.62 mm
Maximum Deflection Force 16.78 kg
Measurement Units Standard
Rate 21.71 N/mm
Rod Size 4.76 mm
SKU D-1301CS
Wire Diameter 1.83 mm x 1.37 mm
