Accurate Screw Machine

W81045HN - Nylon Smooth Shank Swage Mount Spacer

Hexagon smooth shank swage spacer manufactured from Nylon with an 0.3125 Inch outside diameter, length of 0.5625 Inch and 0.234 Inch shank diameter.

Download CAD
Unit System
Specs (in standard)
Label Value
Brand Accurate Screw
Display Name W81045HN
Finish None
Inside Diameter 0.14 in
Length L 0.5625 in
Material Nylon
Measurement Units Standard
Outside Diameter 0.3125 in
Shank Outside Diameter 0.234 in
Shape Hexagon
Spacer Option Standard
Swage Punch Anvil P-5 / HA-58
Thread Size 8-32
Specs (in metric)
Label Value
Brand Accurate Screw
Display Name W81045HN
Finish None
Inside Diameter 3.56 mm
Length L 14.29 mm
Material Nylon
Measurement Units Standard
Outside Diameter 7.94 mm
Shank Outside Diameter 5.94 mm
Shape Hexagon
Spacer Option Standard
Swage Punch Anvil P-5 / HA-58
Thread Size 8-32
