5683CS - 1.44 Inch Spring Steel Extension Spring

Inventory:
Estimated Lead Time

Regular extension spring in Spring Steel. This spring features an O.D. of 0.343 Inch and an initial tension of 2 Pound.

Download CAD
Unit System
Specs (in standard)
Label Value
Brand Century Spring
Display Name 5683
Ends Machine Hook
Finish Zinc
Initial Tension 2 lb
Length 1.44 in
Material Spring Steel
Outside Diameter 0.343 in
Part Type Standard
Rate 16 lbs/in
SKU 5683CS
Sugg Max Deflection 0.61 in
Sugg Max Load 12 lbf
Wire Diameter 0.048 in
Specs (in metric)
Label Value
Brand Century Spring
Display Name 5683
Ends Machine Hook
Finish Zinc
Initial Tension 0.91 kg
Length 36.58 mm
Material Spring Steel
Outside Diameter 8.71 mm
Part Type Standard
Rate 2.8 N/mm
SKU 5683CS
Sugg Max Deflection 15.49 mm
Sugg Max Load 53.38 N
Wire Diameter 1.22 mm
