Century Spring

R-1CS - 0.094 Inch O.D. Long Compression Spring

Inventory Status
Estimated Lead Time

Long-length compression spring in Carbon Steel. This spring features an O.D. of 0.094 Inch, and an I.D. of 0.068 Inch.

Download CAD
Unit System
Specs (in standard)
Label Value
Brand Century Spring
Display Name R-1
Finish None
Inside Diameter 0.068 in
Length 36 in
Material Carbon Steel
Measurement Units Standard
Outside Diameter 0.094 in
Pitch 0.028 in
Product Image R_1CS
Rate 2.1996 lbs/in
Rate Constant 0.1833 lbf
SKU R-1CS
Solid Length Constant 0.48 in
Solid Length Per 0.48 lb
Suggested Max Load 1 lbf
Wire Diameter 0.013 in
Specs (in metric)
Label Value
Brand Century Spring
Display Name R-1
Finish None
Inside Diameter 1.73 mm
Length 914.4 mm
Material Carbon Steel
Measurement Units Standard
Outside Diameter 2.39 mm
Pitch 0.71 mm
Product Image R_1CS
Rate 0.39 N-mm
Rate Constant 32.1 N
SKU R-1CS
Solid Length Constant 12.19 mm
Solid Length Per 0.22 kg
Suggested Max Load 4.45 N
Wire Diameter 0.33 mm
