Century Spring

DJ-50X90GCS - 90 Millimeter Heavy Duty Metric Die Spring

Inventory Status
Estimated Lead Time

Metric die spring with Powder Coat finish meant for Heavy duty. This spring is 90 Millimeter long and has a 340 Newtons per Millimeter spring rate.

Download CAD
Unit System
Specs (in standard)
Label Value
Brand Century Spring
Deflection 1 0.8504 in
Deflection 2 0.7795 in
Deflection 3 0.6732 in
Display Name DJ-50X90G
Duty Load Heavy
Finish Powder Coat
Finish Color Green
Free Length 3.5433 in
Hole Size 1.9685 in
Load 1 1653.5522 lbf
Load 2 1488.1969 lbf
Load 3 1322.8417 lbf
Material Chrome Alloy
Measurement Units Metric
Rate 1941.7476 lbs/in
Rod Size 0.9843 in
SKU DJ-50X90GCS
Specs (in metric)
Label Value
Brand Century Spring
Deflection 1 21.6 mm
Deflection 2 19.8 mm
Deflection 3 17.1 mm
Display Name DJ-50X90G
Duty Load Heavy
Finish Powder Coat
Finish Color Green
Free Length 90 mm
Hole Size 50 mm
Load 1 7355 N
Load 2 6619.5 N
Load 3 5884 N
Material Chrome Alloy
Measurement Units Metric
Rate 340 N/mm
Rod Size 25 mm
SKU DJ-50X90GCS
