DJ-27X150BRCS - 150 Millimeter Extra Heavy Duty Metric Die Spring

Inventory:
Estimated Lead Time

Metric die spring with Powder Coat finish meant for Extra Heavy duty. This spring is 150 Millimeter long and has a 95.4 Newtons per Millimeter spring rate.

Download CAD
Unit System
Specs (in standard)
Label Value
Brand Century Spring
Deflection 1 1.1811 in
Deflection 2 1.063 in
Deflection 3 0.9449 in
Display Name DJ-27X150BR
Duty Load Extra Heavy
Finish Powder Coat
Finish Color Brown
Free Length 5.9055 in
Hole Size 1.063 in
Load 1 639.366 lbf
Load 2 575.4272 lbf
Load 3 511.4883 lbf
Material Chrome Alloy
Measurement Units Metric
Rate 544.8315 lbs/in
Rod Size 0.5315 in
SKU DJ-27X150BRCS
Specs (in metric)
Label Value
Brand Century Spring
Deflection 1 30 mm
Deflection 2 27 mm
Deflection 3 24 mm
Display Name DJ-27X150BR
Duty Load Extra Heavy
Finish Powder Coat
Finish Color Brown
Free Length 150 mm
Hole Size 27 mm
Load 1 2843.9 N
Load 2 2559.5 N
Load 3 2275.1 N
Material Chrome Alloy
Measurement Units Metric
Rate 95.4 N/mm
Rod Size 13.5 mm
SKU DJ-27X150BRCS
