Century Spring

DJ-22X45BCS - 45 Millimeter Light Duty Metric Die Spring

Inventory Status
Estimated Lead Time

Metric die spring with Powder Coat finish meant for Light duty. This spring is 45 Millimeter long and has a 36.5 Newtons per Millimeter spring rate.

Download CAD
Unit System
Specs (in standard)
Label Value
Brand Century Spring
Deflection 1 0.7087 in
Deflection 2 0.6378 in
Deflection 3 0.5669 in
Display Name DJ-22X45B
Duty Load Light
Finish Powder Coat
Finish Color Blue
Free Length 1.7717 in
Hole Size 0.8661 in
Load 1 147.7068 lbf
Load 2 132.2842 lbf
Load 3 119.0647 lbf
Material Chrome Alloy
Measurement Units Metric
Rate 208.4523 lbs/in
Rod Size 0.4331 in
SKU DJ-22X45BCS
Specs (in metric)
Label Value
Brand Century Spring
Deflection 1 18 mm
Deflection 2 16.2 mm
Deflection 3 14.4 mm
Display Name DJ-22X45B
Duty Load Light
Finish Powder Coat
Finish Color Blue
Free Length 45 mm
Hole Size 22 mm
Load 1 657 N
Load 2 588.4 N
Load 3 529.6 N
Material Chrome Alloy
Measurement Units Metric
Rate 36.5 N/mm
Rod Size 11 mm
SKU DJ-22X45BCS
