Century Spring

DJ-12X40BRCS - 40 Millimeter Extra Heavy Duty Metric Die Spring

Inventory Status
Estimated Lead Time

Metric die spring with Powder Coat finish meant for Extra Heavy duty. This spring is 40 Millimeter long and has a 71.1 Newtons per Millimeter spring rate.

Download CAD
Unit System
Specs (in standard)
Label Value
Brand Century Spring
Deflection 1 0.315 in
Deflection 2 0.2835 in
Deflection 3 0.252 in
Display Name DJ-12X40BR
Duty Load Extra Heavy
Finish Powder Coat
Finish Color Brown
Free Length 1.5748 in
Hole Size 0.4724 in
Load 1 127.8777 lbf
Load 2 114.6358 lbf
Load 3 101.4164 lbf
Material Chrome Alloy
Measurement Units Metric
Rate 406.0537 lbs/in
Rod Size 0.2362 in
SKU DJ-12X40BRCS
Specs (in metric)
Label Value
Brand Century Spring
Deflection 1 8 mm
Deflection 2 7.2 mm
Deflection 3 6.4 mm
Display Name DJ-12X40BR
Duty Load Extra Heavy
Finish Powder Coat
Finish Color Brown
Free Length 40 mm
Hole Size 12 mm
Load 1 568.8 N
Load 2 509.9 N
Load 3 451.1 N
Material Chrome Alloy
Measurement Units Metric
Rate 71.1 N/mm
Rod Size 6 mm
SKU DJ-12X40BRCS
