Century Spring

D-305716CS - 102 Millimeter Heavy Duty Metric Die Spring

Inventory Status
Estimated Lead Time

Metric die spring with Powder Coat finish meant for Heavy duty. This spring is 102 Millimeter long and has a 170.3 Newtons per Millimeter spring rate.

Download CAD
Unit System
Specs (in standard)
Label Value
Brand Century Spring
Deflection 1 0.8031 in
Deflection 2 1.0039 in
Deflection 3 1.2047 in
Display Name D-305716
Duty Load Heavy
Finish Powder Coat
Finish Color Red
Free Length 4.0157 in
Hole Size 1.5748 in
Load 1 781.25 lbf
Load 2 976.6187 lbf
Load 3 1171.7626 lbf
Load At Max Deflection 1344.1996 lbf
Material Chrome Silicon
Max Deflection 1.3819 in
Measurement Units Metric
Rate 972.5871 lbs/in
Rod Size 0.7874 in
SKU D-305716CS
Specs (in metric)
Label Value
Brand Century Spring
Deflection 1 20.4 mm
Deflection 2 25.5 mm
Deflection 3 30.6 mm
Display Name D-305716
Duty Load Heavy
Finish Powder Coat
Finish Color Red
Free Length 102 mm
Hole Size 40 mm
Load 1 3475 N
Load 2 4344 N
Load 3 5212 N
Load At Max Deflection 5979 N
Material Chrome Silicon
Max Deflection 35.1 mm
Measurement Units Metric
Rate 170.3 N/mm
Rod Size 20 mm
SKU D-305716CS
