Century Spring

D-1464CS - 2.5 Inch Chrome Alloy Die Spring

Inventory Status
Estimated Lead Time

2.5 Inch Chrome Alloy die spring

Download CAD
Unit System
Specs (in standard)
Label Value
Average Life Deflection Force 1104 lb
Brand Century Spring
Deflection For Average Life 0.38 in
Deflection For Long Life 0.5 in
Display Name D-1464
Duty Load Extra Heavy
Finish None
Finish Color Green
Free Length 2.5 in
Hole Size 1.5 in
Long Life Deflection Force 1472 lb
Material Chrome Alloy
Maximum Deflection 0.63 in
Maximum Deflection Force 1840 lb
Measurement Units Standard
Rate 2944 lbs/in
Rod Size 0.75 in
SKU D-1464CS
Wire Diameter 0.35 in x 0.3 in
Specs (in metric)
Label Value
Average Life Deflection Force 500.68 kg
Brand Century Spring
Deflection For Average Life 9.65 mm
Deflection For Long Life 12.7 mm
Display Name D-1464
Duty Load Extra Heavy
Finish None
Finish Color Green
Free Length 63.5 mm
Hole Size 38.1 mm
Long Life Deflection Force 667.57 kg
Material Chrome Alloy
Maximum Deflection 16 mm
Maximum Deflection Force 834.47 kg
Measurement Units Standard
Rate 515.49 N/mm
Rod Size 19.05 mm
SKU D-1464CS
Wire Diameter 8.89 mm x 7.62 mm
