Century Spring

D-1454CS - 3 Inch Chrome Alloy Die Spring

Inventory Status
Estimated Lead Time

3 Inch Chrome Alloy die spring

Download CAD
Unit System
Specs (in standard)
Label Value
Average Life Deflection Force 533 lb
Brand Century Spring
Deflection For Average Life 0.45 in
Deflection For Long Life 0.6 in
Display Name D-1454
Duty Load Extra Heavy
Finish None
Finish Color Green
Free Length 3 in
Hole Size 1.25 in
Long Life Deflection Force 710 lb
Material Chrome Alloy
Maximum Deflection 0.75 in
Maximum Deflection Force 888 lb
Measurement Units Standard
Rate 1184 lbs/in
Rod Size 0.625 in
SKU D-1454CS
Wire Diameter 0.295 in x 0.225 in
Specs (in metric)
Label Value
Average Life Deflection Force 241.72 kg
Brand Century Spring
Deflection For Average Life 11.43 mm
Deflection For Long Life 15.24 mm
Display Name D-1454
Duty Load Extra Heavy
Finish None
Finish Color Green
Free Length 76.2 mm
Hole Size 31.75 mm
Long Life Deflection Force 322 kg
Material Chrome Alloy
Maximum Deflection 19.05 mm
Maximum Deflection Force 402.72 kg
Measurement Units Standard
Rate 207.32 N/mm
Rod Size 15.88 mm
SKU D-1454CS
Wire Diameter 7.49 mm x 5.72 mm
