Century Spring

CF3300CS - 2 Inch x 52 Inch Constant Force Spring

Inventory Status
Estimated Lead Time

33 Pound constant force spring - 2 Inch by 52 Inch with a hole diameter of 0.253 Inch.

Download CAD
Unit System
Specs (in standard)
Label Value
Brand Century Spring
Display Name CF3300
Distance Between Holes 0.758 in
Drum Diameter 2.136 in
Finish None
Hole Diameter 0.253 in
Inside Diameter 1.85 in
Length 52 in
Load 33 lb
Material Spring Steel
Measurement Units Standard
Number of Holes 2
SKU CF3300CS
Thickness 0.025 in
Width 2 in
Specs (in metric)
Label Value
Brand Century Spring
Display Name CF3300
Distance Between Holes 19.25 mm
Drum Diameter 54.25 mm
Finish None
Hole Diameter 6.43 mm
Inside Diameter 46.99 mm
Length 1320.8 mm
Load 14.97 kg
Material Spring Steel
Measurement Units Standard
Number of Holes 2
SKU CF3300CS
Thickness 0.64 mm
Width 50.8 mm
