Century Spring

CF1320CS - 1 Inch x 40 Inch Constant Force Spring

Inventory Status
Estimated Lead Time

13.2 Pound constant force spring - 1 Inch by 40 Inch with a hole diameter of 0.19 Inch.

Download CAD
Unit System
Specs (in standard)
Label Value
Brand Century Spring
Display Name CF1320
Drum Diameter 1.368 in
Finish None
Hole Diameter 0.19 in
Inside Diameter 1.46 in
Length 40 in
Load 13.2 lb
Material Spring Steel
Measurement Units Standard
Number of Holes 1
SKU CF1320CS
Thickness 0.02 in
Width 1 in
Specs (in metric)
Label Value
Brand Century Spring
Display Name CF1320
Drum Diameter 34.75 mm
Finish None
Hole Diameter 4.83 mm
Inside Diameter 37.08 mm
Length 1016 mm
Load 5.99 kg
Material Spring Steel
Measurement Units Standard
Number of Holes 1
SKU CF1320CS
Thickness 0.51 mm
Width 25.4 mm
