Century Spring

B10-33CS - 2.63" Music Wire Compression Spring

Inventory Status
Estimated Lead Time

Compression spring manufactured from music wire with 4 coils and closed & ground ends. This spring features an O.D. of 0.281", and an I.D. of 0.225".

NOTE: The spring rate value for compression springs with 4 coils or less is a reference value.

Download CAD
Unit System
Specs (in standard)
Label Value
Brand Century Spring
Display Name B10-33
Ends Closed & Ground
Finish None
Free Length 2.63 in
Inside Diameter 0.225 in
Material Music Wire
Outside Diameter 0.281 in
Part Type Standard
Rate 27 lbs/in
SKU B10-33CS
Solid Length 0.11 in
Suggested Max Deflection 0.16 in
Suggested Max Load 4.4 lbf
Total Coils 4
Wire Diameter 0.028 in
Specs (in metric)
Label Value
Brand Century Spring
Display Name B10-33
Ends Closed & Ground
Finish None
Free Length 66.8 mm
Inside Diameter 5.72 mm
Material Music Wire
Outside Diameter 7.14 mm
Part Type Standard
Rate 4.73 N/mm
SKU B10-33CS
Solid Length 2.79 mm
Suggested Max Deflection 4.06 mm
Suggested Max Load 19.57 N
Total Coils 4
Wire Diameter 0.71 mm
The compression spring B10-33CS is an essential component designed for applications requiring reliable force and energy storage. Crafted from high-quality music wire, the B10-33 compression spring design exhibits exceptional tensile strength and resilience.

The B10-33 design is manufactured with a free length of 2.63", with an outer diameter of 0.281", an inner diameter of 0.225", and a total of 4 coils, expertly designed to deliver consistent compression characteristics including a rate of 27 lbs/in.

The B10-33CS compression spring is ideally suited for use in a wide range of mechanical assemblies, including but not limited to automotive suspension systems, industrial machinery, and electronic devices.

In summary, the compression spring B10-33 design stands out for its superior material properties, thoughtful design, and versatility in application. It is a prime choice for engineers committed to excellence and innovation in their projects.
