B-57CS - 0.34" Music Wire Compression Spring
| Inventory Status |
|
|---|---|
| Estimated Lead Time | |
Compression spring manufactured from music wire with 8 coils and closed ends. This spring features an O.D. of 0.125", and an I.D. of 0.073".
| Label | Value |
|---|---|
| Brand | Century Spring |
| Display Name | B-57 |
| Ends | Closed |
| Finish | None |
| Free Length | 0.34 in |
| Inside Diameter | 0.073 in |
| Material | Music Wire |
| Outside Diameter | 0.125 in |
| Part Type | Standard |
| Rate | 113 lbs/in |
| SKU | B-57CS |
| Solid Length | 0.23 in |
| Suggested Max Deflection | 0.06 in |
| Suggested Max Load | 7.3 lbf |
| Total Coils | 8 |
| Wire Diameter | 0.026 in |
| Label | Value |
|---|---|
| Brand | Century Spring |
| Display Name | B-57 |
| Ends | Closed |
| Finish | None |
| Free Length | 8.64 mm |
| Inside Diameter | 1.85 mm |
| Material | Music Wire |
| Outside Diameter | 3.18 mm |
| Part Type | Standard |
| Rate | 19.79 N/mm |
| SKU | B-57CS |
| Solid Length | 5.84 mm |
| Suggested Max Deflection | 1.52 mm |
| Suggested Max Load | 32.47 N |
| Total Coils | 8 |
| Wire Diameter | 0.66 mm |
The B-57 compression spring is engineered for optimal performance in demanding applications. Constructed from high-quality music wire and designed with precision and durability in mind, this spring is an essential component for a variety of mechanical systems where reliable force and resilience are paramount.
The B-57CS compression spring is designed with a free length of 0.41" total of 6 coils, and a rate of 66 lbs/in providing a balanced combination of flexibility and strength. This spring coil, and its closed & ground end configuration allows for efficient energy storage and release, making it suitable for applications requiring precise motion control.
The B-57 spring design is ideal for use in industrial machinery, automotive systems, and various mechanical assemblies where reliable force application is crucial. Its robust construction and thoughtful design make it a dependable choice for engineers seeking a high-performance spring solution.
The B-57CS compression spring is designed with a free length of 0.41" total of 6 coils, and a rate of 66 lbs/in providing a balanced combination of flexibility and strength. This spring coil, and its closed & ground end configuration allows for efficient energy storage and release, making it suitable for applications requiring precise motion control.
The B-57 spring design is ideal for use in industrial machinery, automotive systems, and various mechanical assemblies where reliable force application is crucial. Its robust construction and thoughtful design make it a dependable choice for engineers seeking a high-performance spring solution.
