Maryland Precision Spring

AM-20010210 - 4.02 Inch ID 7.87 Inch OD 1075 High Carbon Steel Disc Spring Washer

Inventory:
Estimated Lead Time

Disc spring manufactured from 1075 High Carbon Steel with an inside diameter of 4.02 Inch and an outside diameter of 7.87 Inch.

Unit System
Specs (in standard)
Label Value
Brand Maryland Precision Spring
Calculated Load at Approximate Deflection 13575 lb
Deflection at 100% Height 0.2477 in
Deflection at 50% Height 0.1238 in
Deflection at 75% Height 0.1858 in
Display Name AM-20010210
Finish None
Inside Diameter 4.02 in
Load at 100% Height 41963 lb
Load at 50% Height 24507 lb
Load at 75% Height 33676 lb
Material 1075 High Carbon Steel
Measurement Units Standard
Outside Diameter 7.87 in
Outside Height 0.6142 in
SKU AM-20010210
T 0.37 in
h/t 0.669 in
Specs (in metric)
Label Value
Brand Maryland Precision Spring
Calculated Load at Approximate Deflection 6156.46 kg
Deflection at 100% Height 6.29 mm
Deflection at 50% Height 3.14 mm
Deflection at 75% Height 4.72 mm
Display Name AM-20010210
Finish None
Inside Diameter 102.11 mm
Load at 100% Height 19030.84 kg
Load at 50% Height 11114.29 kg
Load at 75% Height 15272.56 kg
Material 1075 High Carbon Steel
Measurement Units Standard
Outside Diameter 199.9 mm
Outside Height 15.6 mm
SKU AM-20010210
T 9.4 mm
h/t 16.99 mm
