Maryland Precision Spring

AK-6000 - 0.563 Inch ID 1.012 Inch OD 1075 Steel Disc Spring Washer

Inventory:
Estimated Lead Time

Disc spring manufactured from 1075 Steel with an inside diameter of 0.563 Inch and an outside diameter of 1.012 Inch.

Unit System
Specs (in standard)
Label Value
Ball Bearing Size 6000, 629
Brand Maryland Precision Spring
Deflection at 75% Height 0.015 in
Display Name AK-6000
Finish Phosphate
Inside Diameter 0.563 in
Load at 75% Height 14.5 lb
Material 1075 Steel
Measurement Units Standard
Outside Diameter 1.012 in
Outside Height 0.035 in
SKU AK-6000
T 0.016 in
Specs (in metric)
Label Value
Ball Bearing Size 6000, 629
Brand Maryland Precision Spring
Deflection at 75% Height 0.38 mm
Display Name AK-6000
Finish Phosphate
Inside Diameter 14.3 mm
Load at 75% Height 6.58 kg
Material 1075 Steel
Measurement Units Standard
Outside Diameter 25.7 mm
Outside Height 0.89 mm
SKU AK-6000
T 0.41 mm
