Century Spring

A13-3CS - 0.88" 302/304 Stainless Steel Compression Spring

Inventory Status
Estimated Lead Time

Compression spring manufactured from 302/304 stainless steel with 10.3 coils and closed & ground ends. This spring features an O.D. of 0.25", and an I.D. of 0.196".

Download CAD
Unit System
Specs (in standard)
Label Value
Brand Century Spring
Display Name A13-3
Ends Closed & Ground
Finish None
Free Length 0.88 in
Inside Diameter 0.196 in
Material 302/304 Stainless Steel
Outside Diameter 0.25 in
Part Type Standard
Rate 7.4 lbs/in
SKU A13-3CS
Solid Length 0.28 in
Suggested Max Deflection 0.4 in
Suggested Max Load 2.9 lbf
Total Coils 10.3
Wire Diameter 0.027 in
Specs (in metric)
Label Value
Brand Century Spring
Display Name A13-3
Ends Closed & Ground
Finish None
Free Length 22.35 mm
Inside Diameter 4.98 mm
Material 302/304 Stainless Steel
Outside Diameter 6.35 mm
Part Type Standard
Rate 1.3 N/mm
SKU A13-3CS
Solid Length 7.11 mm
Suggested Max Deflection 10.16 mm
Suggested Max Load 12.9 N
Total Coils 10.3
Wire Diameter 0.69 mm
The compression spring A13-3CS is an essential component designed for applications requiring reliable force and energy storage. Crafted from high-quality 302/304 stainless steel, the A13-3 compression spring design exhibits exceptional tensile strength and resilience.

The A13-3 design is manufactured with a free length of 0.88", with an outer diameter of 0.25", an inner diameter of 0.196", and a total of 10.3 coils, expertly designed to deliver consistent compression characteristics including a rate of 7.4 lbs/in.

The A13-3CS compression spring is ideally suited for use in a wide range of mechanical assemblies, including but not limited to automotive suspension systems, industrial machinery, and electronic devices.

In summary, the compression spring A13-3 design stands out for its superior material properties, thoughtful design, and versatility in application. It is a prime choice for engineers committed to excellence and innovation in their projects.
