Century Spring

72833CS - 2" Music Wire Compression Spring

Inventory Status
Estimated Lead Time

Compression spring manufactured from music wire with 6 coils and closed & ground ends. This spring features an O.D. of 1.46", and an I.D. of 1.136".

Download CAD
Unit System
Specs (in standard)
Label Value
Brand Century Spring
Display Name 72833
Ends Closed & Ground
Finish None
Free Length 2 in
Inside Diameter 1.136 in
Material Music Wire
Outside Diameter 1.46 in
Part Type Standard
Rate 114 lbs/in
SKU 72833CS
Solid Length 0.97 in
Suggested Max Deflection 1 in
Suggested Max Load 117 lbf
Total Coils 6
Wire Diameter 0.162 in
Specs (in metric)
Label Value
Brand Century Spring
Display Name 72833
Ends Closed & Ground
Finish None
Free Length 50.8 mm
Inside Diameter 28.85 mm
Material Music Wire
Outside Diameter 37.08 mm
Part Type Standard
Rate 19.96 N/mm
SKU 72833CS
Solid Length 24.64 mm
Suggested Max Deflection 25.4 mm
Suggested Max Load 520.42 N
Total Coils 6
Wire Diameter 4.11 mm
The 72833CS compression spring is a meticulously engineered component designed for a wide range of industrial applications requiring reliable performance and durability. Crafted from premium 0.162" diameter music wire, the 72833 spring design exhibits reliable strength across its 6 active coils, withstanding repeated compression cycles with a maximum load of 117 lbf without succumbing to fatigue.

We manufacture the 72833 design to provide a compression spring that is 2" long at rest and provides a consistent rate of 114 lbs/in along its recommended maximum of 1" deflection. For best results, your application should fully accommodate the inner (1.136") and outer (1.46") diameters of this spring and be designed for its closed & ground end configuration.
