68747SCS - 2.03" 316 Stainless Steel Compression Spring
| Inventory Status |
|
|---|---|
| Estimated Lead Time | |
Compression spring manufactured from 316 stainless steel with 19.8 coils and closed & ground ends. This spring features an O.D. of 0.375", and an I.D. of 0.231".
| Label | Value |
|---|---|
| Brand | Century Spring |
| Display Name | 68747S |
| Ends | Closed & Ground |
| Finish | Passivated |
| Free Length | 2.03 in |
| Inside Diameter | 0.231 in |
| Material | 316 Stainless Steel |
| Outside Diameter | 0.375 in |
| Part Type | Standard |
| Rate | 67.841 lbs/in |
| SKU | 68747SCS |
| Solid Length | 1.426 in |
| Suggested Max Deflection | 0.389 in |
| Suggested Max Load | 26.39 lbf |
| Total Coils | 19.8 |
| Wire Diameter | 0.072 in |
| Label | Value |
|---|---|
| Brand | Century Spring |
| Display Name | 68747S |
| Ends | Closed & Ground |
| Finish | Passivated |
| Free Length | 51.56 mm |
| Inside Diameter | 5.87 mm |
| Material | 316 Stainless Steel |
| Outside Diameter | 9.53 mm |
| Part Type | Standard |
| Rate | 11.88 N/mm |
| SKU | 68747SCS |
| Solid Length | 36.22 mm |
| Suggested Max Deflection | 9.88 mm |
| Suggested Max Load | 117.38 N |
| Total Coils | 19.8 |
| Wire Diameter | 1.83 mm |
The compression spring 68747SCS is an essential component designed for applications requiring reliable force and energy storage. Crafted from high-quality 316 stainless steel, the 68747S compression spring design exhibits exceptional tensile strength and resilience.
The 68747S design is manufactured with a free length of 2.03", with an outer diameter of 0.375", an inner diameter of 0.231", and a total of 19.8 coils, expertly designed to deliver consistent compression characteristics including a rate of 67.841 lbs/in.
The 68747SCS compression spring is ideally suited for use in a wide range of mechanical assemblies, including but not limited to automotive suspension systems, industrial machinery, and electronic devices.
In summary, the compression spring 68747S design stands out for its superior material properties, thoughtful design, and versatility in application. It is a prime choice for engineers committed to excellence and innovation in their projects.
The 68747S design is manufactured with a free length of 2.03", with an outer diameter of 0.375", an inner diameter of 0.231", and a total of 19.8 coils, expertly designed to deliver consistent compression characteristics including a rate of 67.841 lbs/in.
The 68747SCS compression spring is ideally suited for use in a wide range of mechanical assemblies, including but not limited to automotive suspension systems, industrial machinery, and electronic devices.
In summary, the compression spring 68747S design stands out for its superior material properties, thoughtful design, and versatility in application. It is a prime choice for engineers committed to excellence and innovation in their projects.
