Century Spring

66329SCS - 0.25" 316 Stainless Steel Compression Spring

Inventory Status
Estimated Lead Time

Compression spring manufactured from 316 stainless steel with 5 coils and closed & ground ends. This spring features an O.D. of 0.156", and an I.D. of 0.106".

Download CAD
Unit System
Specs (in standard)
Label Value
Brand Century Spring
Display Name 66329S
Ends Closed & Ground
Finish Passivated
Free Length 0.25 in
Inside Diameter 0.106 in
Material 316 Stainless Steel
Outside Diameter 0.156 in
Part Type Standard
Rate 72.399 lbs/in
SKU 66329SCS
Solid Length 0.125 in
Suggested Max Deflection 0.041 in
Suggested Max Load 2.968 lbf
Total Coils 5
Wire Diameter 0.025 in
Specs (in metric)
Label Value
Brand Century Spring
Display Name 66329S
Ends Closed & Ground
Finish Passivated
Free Length 6.35 mm
Inside Diameter 2.69 mm
Material 316 Stainless Steel
Outside Diameter 3.96 mm
Part Type Standard
Rate 12.68 N/mm
SKU 66329SCS
Solid Length 3.18 mm
Suggested Max Deflection 1.04 mm
Suggested Max Load 13.2 N
Total Coils 5
Wire Diameter 0.64 mm
The compression spring 66329SCS is an essential component designed for applications requiring reliable force and energy storage. Crafted from high-quality 316 stainless steel, the 66329S compression spring design exhibits exceptional tensile strength and resilience.

The 66329S design is manufactured with a free length of 0.25", with an outer diameter of 0.156", an inner diameter of 0.106", and a total of 5 coils, expertly designed to deliver consistent compression characteristics including a rate of 72.399 lbs/in.

The 66329SCS compression spring is ideally suited for use in a wide range of mechanical assemblies, including but not limited to automotive suspension systems, industrial machinery, and electronic devices.

In summary, the compression spring 66329S design stands out for its superior material properties, thoughtful design, and versatility in application. It is a prime choice for engineers committed to excellence and innovation in their projects.
