Century Spring

65468SCS - 1.575" 316 Stainless Steel Compression Spring

Inventory Status
Estimated Lead Time

Compression spring manufactured from 316 stainless steel with 14.18 coils and closed & ground ends. This spring features an O.D. of 0.295", and an I.D. of 0.231".

Download CAD
Unit System
Specs (in standard)
Label Value
Brand Century Spring
Display Name 65468S
Ends Closed & Ground
Finish Passivated
Free Length 1.575 in
Inside Diameter 0.231 in
Material 316 Stainless Steel
Outside Diameter 0.295 in
Part Type Metric
Rate 5.52 lbs/in
SKU 65468SCS
Solid Length 0.445 in
Suggested Max Deflection 0.612 in
Suggested Max Load 3.38 lbf
Total Coils 14.18
Wire Diameter 0.032 in
Specs (in metric)
Label Value
Brand Century Spring
Display Name 65468S
Ends Closed & Ground
Finish Passivated
Free Length 40.01 mm
Inside Diameter 5.87 mm
Material 316 Stainless Steel
Outside Diameter 7.49 mm
Part Type Metric
Rate 0.97 N/mm
SKU 65468SCS
Solid Length 11.3 mm
Suggested Max Deflection 15.54 mm
Suggested Max Load 15.03 N
Total Coils 14.18
Wire Diameter 0.81 mm
The 65468SCS compression spring is a meticulously engineered component designed for a wide range of industrial applications requiring reliable performance and durability. Crafted from premium 0.032" diameter 316 stainless steel, the 65468S spring design exhibits reliable strength across its 14.18 active coils, withstanding repeated compression cycles with a maximum load of 3.38 lbf without succumbing to fatigue.

We manufacture the 65468S design to provide a compression spring that is 1.575" long at rest and provides a consistent rate of 5.52 lbs/in along its recommended maximum of 0.612" deflection. For best results, your application should fully accommodate the inner (0.231") and outer (0.295") diameters of this spring and be designed for its closed & ground end configuration.
