Century Spring

5512CS - 2.94 Inch Spring Steel Extension Spring

Inventory Status
Estimated Lead Time

Regular extension spring in Spring Steel. This spring features an O.D. of 0.781 Inch and an initial tension of 7.7 Pound.

Download CAD
Unit System
Specs (in standard)
Label Value
Brand Century Spring
Display Name 5512
Ends Machine Hook
Finish Zinc
Initial Tension 7.7 lb
Length 2.94 in
Material Spring Steel
Outside Diameter 0.781 in
Part Type Standard
Rate 19 lbs/in
SKU 5512CS
Sugg Max Deflection 1.4 in
Sugg Max Load 34 lbf
Wind Direction Left
Wire Diameter 0.095 in
Specs (in metric)
Label Value
Brand Century Spring
Display Name 5512
Ends Machine Hook
Finish Zinc
Initial Tension 3.49 kg
Length 74.68 mm
Material Spring Steel
Outside Diameter 19.84 mm
Part Type Standard
Rate 3.33 N/mm
SKU 5512CS
Sugg Max Deflection 35.56 mm
Sugg Max Load 151.23 N
Wind Direction Left
Wire Diameter 2.41 mm
