5418CS - 0.44 Inch Music Wire Extension Spring

Inventory:
Estimated Lead Time

Regular extension spring in Music Wire. This spring features an O.D. of 0.078 Inch and an initial tension of 0.05 Pound.

Download CAD
Unit System
Specs (in standard)
Label Value
Brand Century Spring
Display Name 5418
Ends Machine Hook
Finish None
Initial Tension 0.05 lb
Length 0.44 in
Material Music Wire
Outside Diameter 0.078 in
Part Type Standard
Rate 1 lbs/in
SKU 5418CS
Sugg Max Deflection 0.47 in
Sugg Max Load 0.54 lbf
Wire Diameter 0.009 in
Specs (in metric)
Label Value
Brand Century Spring
Display Name 5418
Ends Machine Hook
Finish None
Initial Tension 0.02 kg
Length 11.18 mm
Material Music Wire
Outside Diameter 1.98 mm
Part Type Standard
Rate 0.18 N/mm
SKU 5418CS
Sugg Max Deflection 11.94 mm
Sugg Max Load 2.4 N
Wire Diameter 0.23 mm
