5266CS - 7.88 Inch Music Wire Extension Spring

Inventory:
Estimated Lead Time

Regular extension spring in Music Wire. This spring features an O.D. of 0.234 Inch and an initial tension of 0.6 Pound.

Download CAD
Unit System
Specs (in standard)
Label Value
Brand Century Spring
Display Name 5266
Ends Machine Hook
Finish Zinc
Initial Tension 0.6 lb
Length 7.88 in
Material Music Wire
Outside Diameter 0.234 in
Part Type Standard
Rate 0.38 lbs/in
SKU 5266CS
Sugg Max Deflection 11 in
Sugg Max Load 4.7 lbf
Wire Diameter 0.028 in
Specs (in metric)
Label Value
Brand Century Spring
Display Name 5266
Ends Machine Hook
Finish Zinc
Initial Tension 0.27 kg
Length 200.15 mm
Material Music Wire
Outside Diameter 5.94 mm
Part Type Standard
Rate 0.07 N/mm
SKU 5266CS
Sugg Max Deflection 279.4 mm
Sugg Max Load 20.91 N
Wire Diameter 0.71 mm
