10916CS - 1.63" Spring Steel Compression Spring

Inventory:
Estimated Lead Time

Compression spring manufactured from spring steel with 18.3 coils and closed ends. This spring features an O.D. of 0.312", and an I.D. of 0.208".

Download CAD
Unit System
Specs (in standard)
Label Value
Brand Century Spring
Display Name 10916
Ends Closed
Finish None
Free Length 1.63 in
Inside Diameter 0.208 in
Material Spring Steel
Outside Diameter 0.312 in
Part Type Standard
Rate 37 lbs/in
SKU 10916CS
Solid Length 1 in
Suggested Max Deflection 0.42 in
Suggested Max Load 15 lbf
Total Coils 18.3
Wire Diameter 0.052 in
Specs (in metric)
Label Value
Brand Century Spring
Display Name 10916
Ends Closed
Finish None
Free Length 41.4 mm
Inside Diameter 5.28 mm
Material Spring Steel
Outside Diameter 7.92 mm
Part Type Standard
Rate 6.48 N/mm
SKU 10916CS
Solid Length 25.4 mm
Suggested Max Deflection 10.67 mm
Suggested Max Load 66.72 N
Total Coils 18.3
Wire Diameter 1.32 mm
The 10916 compression spring is engineered for optimal performance in demanding applications. Constructed from high-quality spring steel and designed with precision and durability in mind, this spring is an essential component for a variety of mechanical systems where reliable force and resilience are paramount.

The 10916CS compression spring is designed with a free length of 1.5" total of 10.8 coils, and a rate of 2.8 lbs/in providing a balanced combination of flexibility and strength. This spring coil, and its closed & ground end configuration allows for efficient energy storage and release, making it suitable for applications requiring precise motion control.

The 10916 spring design is ideal for use in industrial machinery, automotive systems, and various mechanical assemblies where reliable force application is crucial. Its robust construction and thoughtful design make it a dependable choice for engineers seeking a high-performance spring solution.
