A14-55CS - 0.61" Spring Steel Compression Spring

Inventory Status
Estimated Lead Time

Compression spring manufactured from spring steel with 4 coils and closed & ground ends. This spring features an O.D. of 0.5", and an I.D. of 0.42".

NOTE: The spring rate value for compression springs with 4 coils or less is a reference value.

Download CAD
Unit System
Specs (in standard)
Label Value
Brand Century Spring
Display Name A14-55
Ends Closed & Ground
Finish Gold Iridite
Free Length 0.61 in
Inside Diameter 0.42 in
Material Spring Steel
Outside Diameter 0.5 in
Part Type Standard
Rate 19 lbs/in
SKU A14-55CS
Solid Length 0.16 in
Suggested Max Deflection 0.26 in
Suggested Max Load 5 lbf
Total Coils 4
Wire Diameter 0.04 in
The compression spring A14-55CS is an essential component designed for applications requiring reliable force and energy storage. Crafted from high-quality spring steel, the A14-55 compression spring design exhibits exceptional tensile strength and resilience.

The A14-55 design is manufactured with a free length of 0.61", with an outer diameter of 0.5", an inner diameter of 0.42", and a total of 4 coils, expertly designed to deliver consistent compression characteristics including a rate of 19 lbs/in.

The A14-55CS compression spring is ideally suited for use in a wide range of mechanical assemblies, including but not limited to automotive suspension systems, industrial machinery, and electronic devices.

In summary, the compression spring A14-55 design stands out for its superior material properties, thoughtful design, and versatility in application. It is a prime choice for engineers committed to excellence and innovation in their projects.
